Triumph Speed 400 & Scrambler 400 Plug & Play Tail Tidy Kit

Brogue Triumph Speed 400 & Scrambler 400 Tail Tidy kits are in! An easy-to-fit product that uses existing mounting points and requires no modification.

CNC laser-cut and bent from stainless steel and powder-coated black. Each kit comes welded and dressed with a custom harness that can be used alongside our low-profile turn kits or OEM turn signals.

Click HERE to view our installation video

See them in action

This is a multi piece design, that is hand welded for a clean and stylish install with clearances and adequate strength in mind. Each kit comes pre-wired with OEM connections for a true plug and play experience (no need to transfer over your stock tail harness).

WHAT'S INCLUDED

• Stainless steel-cut and hand tig welded tail license plate bracket (powder-coated finish).
• Stainless steel-cut turn bracket (powder-coated finish).
• LED license plate light with built-in plug-and-play harness that can be used with your OEM turn signals or our low-profile turn signal kits.
• Includes all necessary hardware to complete the installation.

Installation Instructions

Step 1 - Disconnect the main harness found underneath the seat (make sure to depress the locking tab).

Step 2 - Remove the four main bolts securing your stock tail piece and set the front two stock bolts aside to be reused with your new Brogue kit.

Step 3 - Remove and install your stock or Brogue low-profile turn signals on your new tail tidy with the provided m6 washers and nuts and secure/cut all zip ties for a clean installation.

Step 4 - Cut the two aft zip ties found at the rear of the tail tidy (they act as placeholders during shipping and must be removed).

Step 5 - Install your new tail kit in reverse, keeping in mind you will reuse the forward two stock bolts/washers, and the rear stack-up is as follows: the provided Allen bolts, thick washers, then the provided spacers (install video time stamp 3:12). Evenly start all hardware to make sure nothing is cross-threaded before torquing everything down (we recommend blue Loctite on all hardware).

Step 6 - Test your lights and ride!

Fitment:

Triumph Speed 400

Triumph Scrambler 400
